Samson SXD5000 Power Amplifier
Key Features
- Impressive power for your performance and installation speaker configurations
- Clear, robust output with 750W per side at four ohms
- Precise control of your sound thanks to advanced DSP technology
- Monitor your levels accurately with multi-segment LED metering
Samson SXD5000 Power Amplifier Overview
All the power you need to get your talent heard. The Samson SXD5000 Power Amplifier offers huge output, crystal clear audio, and advanced control for a variety of pro-level performance and installation speaker configurations. Meticulously engineered for clean, impactful sound, you'll get low distortion and wide dynamic range across an extended frequency response.
Great sound doesn't have to be difficult, and the SXD5000 is proof. Utilising advanced DSP technology, you have full control of your audio. From Crossover management to EQ shaping, the SXD5000 has all the tools you need to get the best from your speaker system. And with fully-editable presets on board, you can get to work in minutes, no matter what the setting.
Precision and practicality. All in one unit. Monitor your levels with ease thanks to multi-segment LED metering on each channel. No matter what volume you need, individual level controls allow you to accurately set gain and sensitivity for the clearest audio possible. All from a unit that fits neatly into a dual rack space. Live sound has never been this easy.
Product Ref: 37381
Full Description
View Full DescriptionClear audio guaranteed
Impressive power. Unrivalled performance. The SXD5000 is an ideal choice for front of house engineers and installers. With a huge 750W per side at 4 ohms, you’ll get clear, impactful sound delivered directly to your installation and performance speaker systems. The SXD5000 is specially engineered for minimal distortion. Utilising an extended frequency range of 20Hz – 20kHz, you’ll get accurate audio reproduction with a wide dynamic range. That means professional-quality sound without the effort.
Ultimate control
A perfect combination of power and precision. Take control of your sound with the SXD5000’s digital DSP interface. Designed to push the boundaries of value, performance, and reliability, the advanced DSP offers a wide range of editable parameters for the best sound possible. Discover high and low pass filters, a 3-band EQ, output limiter, and delay time for speaker alignment. Set up in minutes thanks to four customisable presets, created to provide optimal settings for various speaker configurations. It’s as easy as plug in and play.
The highest standard of reliability
Built for the most demanding environments. Engineer your sound with confidence thanks to the SXD5000’s multi-stage protection. Your power amp is fully protected against power-up, over-heating, over-current, short circuit, low output impedance, and DC voltage. You’ll get maximum performance night after night. With an all-steel chassis, you’ll never have to worry about damages getting in the way of your show.
Features
- Professional-quality power supply for your passive speaker systems
- Best-in-class performance with advanced DSP control, including Crossover, Filter, EQ, Limiter, Delay, and more
- Suitable for most performance and installation speaker configurations
- Huge power with 750W per side at four ohms
- Crystal clear audio guaranteed with minimal distortion across a 20Hz – 20kHz frequency range
- Fully customisable presets for a range of applications, including DJ, live sound, and commercial installations
- Easy-to-navigate front panel with backlit LCD screen
- Monitor your levels with precision thanks to a multi-segment LED meter on each channel
- Connect to any setup with XLR and ¼” inputs, binding post, and Speakon ouputs
- Fits neatly into any 19” rack with a dual rack space design
Specifications
- Rated Output Power Stereo (both channel driven @ 8-ohms): 500W
- Rated Output Power Stereo (both channel driven @ 4-ohms): 750W
- Signal to Noise Ratio (20Hz-20k): 100dB
- Input sensitivity @ 8-ohms Voltage Gain: 5dBu
- Voltage Gain @ 8-ohm: 32dB
- Output Circuitry: 2-Tier Class H
- Current Consumption (115VAC/230VAC) @1/8 rated power 4ohms: 3.8A / 5.36A
- Current Consumption (115VAC/230VAC) @1/3 rated power 4ohms: 10A / 13.6A
- Current Consumption (115VAC/230VAC) @ rated power 4ohms, max: 13.6A / 23.8A
- Distortion (typical @ 4-ohms): 0.02
- Frequency Response @ 8-ohms 1Watt: 0/-1dB: 20Hz-20kHz
- Damping Factor (400Hz): 120
- Input Impedance: 20K ohm (balanced)
- 10Vrms (22dBu)
- Cooling: Continuously variable speed fan cooling
- Connectors (each channel): 3-pin XLR and ¼” TRS, balanced (inputs), Binding post and Speakon® (outputs)
- Controls: Power switch, CH A & CH B volume DSP Controls: UP, DOWN, BACK buttons & EDIT encoder/button
- Indicators: Signal, -20dB, -10dB, Limit, Thermal
- Protection: Short Circuit, Open Circuit, Thermal, RF protection Load protected against DC faults
- DSP Display: 2x16 Character LCD
- DSP Modes: Manual mode, 2 Full Range, Mono 2-Way, Sub/Sat, 2 Subs
- DSP I/O Setting: Stereo, Mono A+B Dual, Mono A+B Link, Parallel A Dual, Parallel A Link
- DSP Digital Dynamics Function: Filter, Crossover, Gain Offset, EQ, Limiter
- DSP Digital Delay Function: Max 20ms per channel
- DSP Digital EQ Function per Channel: f0: 1/12 Octave at 20 20kHz, Gain: +/- 12dB, Q: 0.5 5.0 Presets: DJ, Vocal, Live Sound, Install, Rock, Dance and Jazz
- DSP Setup: Lock Controls with Code, Factory Reset
- Dimensions (L x W x H): 19” x 13” x 3.5” (482mm x 330mm x 88mm)
- Net Weight: 28.6lbs / 13kg
